Name: JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JZP-6.0B-SC
Availability: InStock

家へ > 製品 > ゴム製衝撃吸収材 >

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

起源の場所:

中国

ブランド名:

Hoan

モデル番号:

JZP-6.0B-SC

連絡ください

引金を求めてください

JZP-6.0B-SC Hot Product 2024 Rubber Shock Absorber with 6.7KG Load Range and Condition Monitoring

製品詳細

分離周波数:

5Hz

耐久性:

高い

温度範囲:

広い

使用法:

衝撃や振動を吸収する

色:

黒

製品認証:

ISO 9001

負荷範囲:

6.7KG

Appliocation:

自動車,機械,エンジン

プロダクトキーワード:

摩擦抑制隔離器

設置タイプ:

水平/垂直

料金:

手頃な価格

マーケティングタイプ:

ホット製品2024

共鳴頻度:

30のHZ

ショールームの場所:

なし

ハイライト:

Hot Product 2024 Rubber Shock Absorber

6.7KG Load Range Vibration Isolator

Condition Monitoring Friction Damping Isolator

支払いと送料の条件

最小注文数量

支払条件

L/C、D/A、D/P、T/T、ウェスタンユニオン、マネーグラム

JZP-5.5B-SC Rubber Shock Absorber with Vibration Frequency 5-50Hz and Max Static Load 5.5Kg in 3-24 Inches Length

最高の価格を入手する

JZP-5.0B-SC ゴム製衝撃吸収材、10Hz～100Hz 周波数範囲、車載効率検証用高振動耐性、新製品 2025

最高の価格を入手する

JZP-4.0B-SC Rubber Shock Absorber with M5 Mounting Holes 30mm Height and High Pressure Resistance for Vibration Isolation

最高の価格を入手する

JZP-3.5B-SC モジュラルのゴムショック吸収器 5~6kg 負荷範囲 1:2 圧縮比 40g/11ms 衝撃抵抗

最高の価格を入手する

連絡ください

今連絡してください

製品説明

JZP-6.0B-SC High-Performance Vibration Isolation and Condition Monitoring for Rubber Shock Absorber

JZP-B-SC Series

Towards the Future: Development Prospect of the JZP Series and Intelligent Vibration Isolation Technology

Technology knows no bounds. Xi'an Hoan Microwave Co., Ltd. continues to invest heavily in R&D, focusing on emerging demands for future on-vehicle vibration isolation technology. The JZP Series platform is evolving towards smarter, more integrated, and more active solutions.

Intelligent Vibration Isolation and Condition Monitoring

Future generations of the JZP Series may integrate micro MEMS accelerometers and IoT modules, enabling real-time monitoring of vibration isolation status and equipment vibration magnitude. This data can be uploaded to cloud platforms via wireless networks, supporting predictive maintenance, fleet management optimization, and vehicle Prognostics and Health Management (PHM).

Active and Semi-Active Vibration Isolation Technologies

For ultra-high vibration isolation requirements—such as on-vehicle lithography machines and quantum communication devices—Xi'an Hoan is exploring active/semi-active vibration isolation technologies. Using sensors, controllers, and actuators, this system can achieve precise control over specific frequency vibrations, especially low-frequency ones.

Dimension Parameter Table

Model	D (mm)	H±1 (mm)	h (mm)	A±0.2 (mm)	B (mm)	d	d2	R	B (mm)
JZP-B-SC	46	30	21	40	50	M4	∅5.5	5	22

Technical Parameter Table

Model	Nominal Load (kg)	Static Displacement (mm)	Working Temperature (℃)	Resonance Frequency (Hz)	Impact Test	Valid Period (year)
JZP-1.0B-SC	1.0	≤0.3	-45～+65	41.5±5	100G12times	8
JZP-1.5B-SC	1.5
JZP-2.0B-SC	2.0
JZP-2.5B-SC	2.5
JZP-3.0B-SC	3.0
JZP-3.5B-SC	3.5
JZP-4.0B-SC	4.0
JZP-5.0B-SC	5.0
JZP-5.5B-SC	5.5
JZP-6.0B-SC	6.0

Vibration and Impact Curve of JZP-B-SC Series

Vibration

Impact
