Name: JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption
Brand: Xi'an Hoan Microwave Co., Ltd.
SKU: JMZ-T1-2.0
Availability: InStock

家へ > 製品 > スプリング・アイソレーター >

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

起源の場所:

中国

ブランド名:

Hoan

モデル番号:

JMZ-T1-2.0

連絡ください

引金を求めてください

JMZ-T1-2.0 Spring Isolator with 1 Year Warranty for Industrial and Commercial Applications and High Shock Absorption

製品詳細

互換性:

ほとんどの標準装備に適合します

デザインスタイル:

産業

応用:

産業および商業

コアコンポーネント:

ベアリング

メンテナンス:

メンテナンスが少ない

取り付けタイプ:

ねじ込み

衝撃吸収:

高い

ノイズリダクション:

はい

特徴:

耐久して設置することが簡単

保証:

1年

色:

銀

可用性:

広く利用可能です

ハイライト:

1 Year Warranty Spring Isolator

Industrial and Commercial Application Vibration Isolator

High Shock Absorption Friction Damping Isolator

支払いと送料の条件

最小注文数量

支払条件

L/C、D/A、D/P、T/T、Western Union、MoneyGram

JMZ-T1-1.4 32mm Overall Width Spring Isolator with 1 Year Warranty and High Resilience for Industrial Vibration Isolation

最高の価格を入手する

JMZ-T1-1.2 Spring Isolator with 95% Isolation Efficiency 32mm Overall Width and UL Listed for Vibration Isolation

最高の価格を入手する

JMZ-T1-0.6 Spring Isolator with High Resilience and Strong Shock Resistance for Durable Vibration Control

最高の価格を入手する

JMZ-T1-0.45 Friction Damping Vibration Isolator with Up to 95% Isolation Efficiency for 0-150°F Operating Temperature and 1 Year Warranty

最高の価格を入手する

連絡ください

86-29-88292913

今連絡してください

製品説明

JMZ-T1-2.0 The Ultimate Solution for Equipment Stability and Performance with Spring Isolator

JMZ-T1 Series

Redefining Stability Boundaries: The JMZ-T Series transforms equipment performance foundations into strategic advantages by addressing the critical relationship between installation stability and ultimate accuracy.

In precision engineering, vibration acts as a "precision assassin" originating from both external sources (ground fluctuations, human movement) and internal equipment components. The JMZ-T Series friction damping vibration isolators from Xi'an Hoan Microwave Co., Ltd. go beyond traditional vibration reduction to redefine equipment stability boundaries, converting basic vibration isolation into a core strategic performance advantage.

Unlike traditional solutions (rubber pads or ordinary springs) that may trigger resonance or cause prolonged oscillation, the JMZ-T Series implements proactive "energy management" through:

Innovative multi-stage friction damping mechanism
Precisely controlled internal friction pairs
Efficient conversion of mechanical energy to thermal energy
Rapid stabilization for improved performance

This technology delivers measurable benefits for precision measuring instruments (faster reading stabilization, higher data repeatability) and high-end manufacturing equipment (superior processing consistency, lower scrap rates).

The JMZ-T Series represents a paradigm shift - not just a component, but a "performance amplifier" that unlocks equipment design potential by creating an ideal static working platform.

Structural Dimension Diagram

Technical Parameters

Model	Max PZ-Direction Load	PZ Displacement Under Max Load	H (mm)	h (mm)	d (mm)	Weight (g)	Shock Test	Resonance Frequency (Hz)	Operating Temp Range (℃)
JMZ-T1-0.3	0.3	≤0.6	19.5±0.5	16	M4-7H/ M3-7H	≤58	30g,11ms	＜30	-65～+120
JMZ-T1-0.45	0.45
JMZ-T1-0.6	0.6
JMZ-T1-1.2	1.2		22±0.5	17.5
JMZ-T1-1.4	1.4
JMZ-T1-2.0	2.0

Vibration Curve of JMZ-T1 Series

Impact Curve of JMZ-T1 Series
